Hydraulic discharge machine
Product display
Product introduction
Extruders are usually used together with mixers / mixers, containers, etc. to help high viscosity materials to be emptied from containers, and then distributed, measured and filled. It is suitable for discharging adhesive, silica gel, putty, ink, pigment, etc
Product characteristics
1、Up and down discharging mode can be selected
2、Discharge height can be customized according to customer requirements
3、The outlet can be connected with metering device to realize quantitative discharge
4、The sealing ring of pressure plate is close to the inner wall of the vessel without material residue
5、The head type or flat bottom type can be selected according to the bottom structure of mixing drum
6、The pressure can be adjusted according to the material condition and subsequent metering and filling equipment, and can work continuously under stable pressure
Technical parameter
Model (Mode & Spec.) LHDP-2L LHDP-100L LHDP-300L LHDP-500L LHDP-1000L Electric machinery (Power for Press) Kw 0.37 2.2 4 5.5 7.5/11 Maximum pressure of press (Norminal strength) MT 12 30 60 80 150 Pressure per unit area (Unit pressure of plate) Kg/mg² 15 15 15 15 15 System pressure rating（Rated pressure system） Mpa 25 25 25 25 25 Remarks：
1、The above technical parameters are the basic equipment configuration of Lingyu enterprise, and the specific configuration needs to be adjusted according to the actual production process of users
2、Other models available：LHDP-5L、LHDP-10L、LHDP-15L、LHDP-30L、LHDP-60L、LHDP-200L、LHDP-600L、LHDP-800L、LHDP-1500L、LHDP-2000L。
3、At the same time, users can choose weighing system or filling and sealing system for supporting use
